iRay Dental X-Ray Digital Intra-oral Sensor CMOS Detector Technology High Resolution Pluto 0001X. FDA approved. One year warranty. Pluto 0001X is digital size-1 intra-oral sensor. 20 μm pixel pitch CMOS sensor with CsI scintillator. Ergonomic design with smooth edges, rounded corners, and a flexible cable for maxi-mum patient comfort. Works with TWAIN supported software. TWAIN works well with Dexis.
Important Notes:
1. The sensor comes with its own DR software, which is lifetime free use.
2. Works with TWAIN supported software, Eaglesoft, Dexis and TigerView.
3. The computer operating system adapted by our products is win7, win10, win11.
4. Check before the purchase, make sure your software and PC meet the required specifications for smooth operation.
| Overview |
|
| Technical Parameter |
| Model: | Pluto 0001X | Pluto 0015X | Pluto 0002X |
| Detector Technology: | CMOS | CMOS | CMOS |
| Scintillator: | Direectly deposited CsI: TI | Direectly deposited CsI: TI | Direectly deposited CsI: TI |
| Pixel Pitch (μm): | 20 | 20 | 20 |
| Active Area (mm²): | 20 x 30 | 24 x 33 | 26 x 36 |
| AD Conversion (bit): | 14 | 14 | 14 |
| Exposure Mode: | Smart AED | Smart AED | Smart AED |
| X-ray Exposure Window (s): | Max. 5s | Max. 5s | Max. 5s |
| X-ray Energy Range (kV): | 55～100kV | 55～100kV | 55～100kV |
| Data Interface: | USB 2.0 | USB 2.0 | USB 2.0 |
| Power Dissipation (W): | ≤0.8W | ≤0.8W | ≤0.8W |
| Dimensions (mm3): | 25.03 × 38.53 × 4.5 | 29.2 × 43.5 × 4.5 | 31.62 × 45.0 × 4.5 |
| Length of cable(m): | 3m(Standard), 5m(Option) | 3m(Standard), 5m(Option) | 3m(Standard), 5m(Option) |
| Housing material: | Kevlar | Kevlar | Kevlar |
| X-Ray shielding: | Pb-shield behind active area | Pb-shield behind active area | Pb-shield behind active area |
| Radiation dose: | ≥ 50Gy | ≥ 50Gy | ≥ 50Gy |
| Ingress Protection: | IP68 | IP68 | IP68 |
| Operating Temperature (℃): | 10 ~ 40 | 10 ~ 40 | 10 ~ 40 |
| Storage & Transport Temperature with Package (℃): | -10~60 | -10~60 | -10~60 |
| Operating Humidity (% RH): | 20 ~ 90 (Non-Condensing) | 20 ~ 90 (Non-Condensing) | 20 ~ 90 (Non-Condensing) |
| Storage & Transport Humidity with Package (% RH): | 10 ~ 95 (Non-Condensing) | 10 ~ 95 (Non-Condensing) | 10 ~ 95 (Non-Condensing) |
iRay Dental X-Ray Digital Intra-oral Sensor CMOS Detector Technology High Resolution Pluto 0001X. FDA approved. One year warranty. Pluto 0001X is digital size-1 intra-oral sensor. 20 μm pixel pitch CMOS sensor with CsI scintillator. Ergonomic design with smooth edges, rounded corners, and a flexible cable for maxi-mum patient comfort. Works with TWAIN supported software. TWAIN works well with Dexis.
Important Notes:
1. The sensor comes with its own DR software, which is lifetime free use.
2. Works with TWAIN supported software, Eaglesoft, Dexis and TigerView.
3. The computer operating system adapted by our products is win7, win10, win11.
4. Check before the purchase, make sure your software and PC meet the required specifications for smooth operation.
| Overview |
|
| Technical Parameter |
| Model: | Pluto 0001X | Pluto 0015X | Pluto 0002X |
| Detector Technology: | CMOS | CMOS | CMOS |
| Scintillator: | Direectly deposited CsI: TI | Direectly deposited CsI: TI | Direectly deposited CsI: TI |
| Pixel Pitch (μm): | 20 | 20 | 20 |
| Active Area (mm²): | 20 x 30 | 24 x 33 | 26 x 36 |
| AD Conversion (bit): | 14 | 14 | 14 |
| Exposure Mode: | Smart AED | Smart AED | Smart AED |
| X-ray Exposure Window (s): | Max. 5s | Max. 5s | Max. 5s |
| X-ray Energy Range (kV): | 55～100kV | 55～100kV | 55～100kV |
| Data Interface: | USB 2.0 | USB 2.0 | USB 2.0 |
| Power Dissipation (W): | ≤0.8W | ≤0.8W | ≤0.8W |
| Dimensions (mm3): | 25.03 × 38.53 × 4.5 | 29.2 × 43.5 × 4.5 | 31.62 × 45.0 × 4.5 |
| Length of cable(m): | 3m(Standard), 5m(Option) | 3m(Standard), 5m(Option) | 3m(Standard), 5m(Option) |
| Housing material: | Kevlar | Kevlar | Kevlar |
| X-Ray shielding: | Pb-shield behind active area | Pb-shield behind active area | Pb-shield behind active area |
| Radiation dose: | ≥ 50Gy | ≥ 50Gy | ≥ 50Gy |
| Ingress Protection: | IP68 | IP68 | IP68 |
| Operating Temperature (℃): | 10 ~ 40 | 10 ~ 40 | 10 ~ 40 |
| Storage & Transport Temperature with Package (℃): | -10~60 | -10~60 | -10~60 |
| Operating Humidity (% RH): | 20 ~ 90 (Non-Condensing) | 20 ~ 90 (Non-Condensing) | 20 ~ 90 (Non-Condensing) |
| Storage & Transport Humidity with Package (% RH): | 10 ~ 95 (Non-Condensing) | 10 ~ 95 (Non-Condensing) | 10 ~ 95 (Non-Condensing) |
iRay Dental Digital RVG X-Ray Sensor Pluto 0001X High Resolution
