iRay Dental X-Ray Digital Intra-oral Sensor CMOS Detector Technology High Resolution Pluto 0002X. FDA approved. One year warranty. Pluto 0002X is digital size-2 intra-oral sensor. 20 μm pixel pitch CMOS sensor with CsI scintillator. Ergonomic design with smooth edges, rounded corners, and a flexible cable for maxi-mum patient comfort. Works with TWAIN supported software. TWAIN works well with Dexis.

Important Notes:

1. The sensor comes with its own DR software, which is lifetime free use.
2. Works with TWAIN supported software,  Eaglesoft, Dexis and TigerView.
3. The computer operating system adapted by our products is win7, win10, win11.
4. Check before the purchase, make sure your software and PC meet the required specifications for smooth operation.

Overview
  • CMOS detector technology
  • Low dose clinical imaging
  • High resolution
  • Ensures optimal resolution with a 20 μm pixel pitch CMOS sensor and CSI scintillator.
  • Wide dynamic range
  • Pluto 0002X suitable for adults
  • Slim, rounded corner and smooth edge
  • Direct USB connectivity
  • Easy to Use. Smart and Powerful Software. Waterproof. Durable.
  • AED trigger, fast and easy workflow
  • Durable material and components
  • Friendly software user interface
  • Works with TWAIN supported software. TWAIN works well with Dexis.
Technical Parameter
Model: Pluto 0001X Pluto 0015X Pluto 0002X
Detector Technology: CMOS CMOS CMOS
Scintillator: Direectly deposited CsI: TI Direectly deposited CsI: TI Direectly deposited CsI: TI
Pixel Pitch (μm): 20 20 20
Active Area (mm²): 20 x 30 24 x 33 26 x 36
AD Conversion (bit): 14 14 14
Exposure Mode: Smart AED Smart AED Smart AED
X-ray Exposure Window (s): Max. 5s Max. 5s Max. 5s
X-ray Energy Range (kV): 55～100kV 55～100kV 55～100kV
Data Interface: USB 2.0 USB 2.0 USB 2.0
Power Dissipation (W): ≤0.8W ≤0.8W ≤0.8W
Dimensions (mm3): 25.03 × 38.53 × 4.5 29.2 × 43.5 × 4.5 31.62 × 45.0 × 4.5
Length of cable(m): 3m(Standard), 5m(Option) 3m(Standard), 5m(Option) 3m(Standard), 5m(Option)
Housing material: Kevlar Kevlar Kevlar
X-Ray shielding: Pb-shield behind active area Pb-shield behind active area Pb-shield behind active area
Radiation dose: ≥ 50Gy ≥ 50Gy ≥ 50Gy
Ingress Protection: IP68 IP68 IP68
Operating Temperature (℃): 10 ~ 40 10 ~ 40 10 ~ 40
Storage & Transport Temperature with Package (℃): -10~60 -10~60 -10~60
Operating Humidity (% RH): 20 ~ 90 (Non-Condensing) 20 ~ 90 (Non-Condensing) 20 ~ 90 (Non-Condensing)
Storage & Transport Humidity with Package (% RH): 10 ~ 95 (Non-Condensing) 10 ~ 95 (Non-Condensing) 10 ~ 95 (Non-Condensing)

iRay Dental Digital RVG X-Ray Sensor Pluto 0002X High Resolution

SKU: 22902004+52016002
Free Gift (Pac-Dent SoftEdge Cushions)

Warehouse For US
3-5 business days for delivery.
$1,499.00 $1,999.00
-25%

Payment & Security

  • American Express
  • JCB
  • Mastercard
  • PayPal
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Free Shipping For Payments Amount Over $200

5% OFF for First Order

Coupon Code: NEW5%

6% OFF Over $500 🌟 10% OFF Order Over $1200

 (Auto Discount)

Accepts 60-day Returns and Refunds
